UNIVIEW IPC2325SB-DZK-I0 PRIME-I SERIES AI IP Bullet CCTV Camera - 5MP/2K
Overview
The UNIVIEW IPC2325SB-DZK-I0 PRIME-I Series AI IP Bullet CCTV Camera delivers exceptional image quality and advanced features, making it the ideal choice for comprehensive security monitoring. With a powerful 5MP resolution and cutting-edge AI capabilities, this camera provides unparalleled clarity and intelligent intrusion prevention, ensuring your premises are always protected.
Key Features
High-Quality Imaging:
- Resolution: Capture every detail with a 5MP (2880*1620) CMOS sensor.
- Frame Rates: Enjoy smooth video with multiple resolutions including 5MP @30/25fps, 4MP @30/25fps, 3MP @30/25fps, and 2MP @30/25fps.
Advanced Compression:
- Formats Supported: Ultra 265, H.265, H.264, MJPEG for efficient storage and bandwidth management.
AI-Driven Intrusion Prevention:
- Smart Detection: Includes cross line, intrusion, enter area, and leave area detection.
- Reduced False Alarms: Accurately distinguishes between human, motor vehicle, and non-motor vehicle movements, minimizing false alarms caused by leaves, birds, and lights.
Intelligent Monitoring:
- People Flow Counting: Monitor the number of people entering and exiting.
- Crowd Density Monitoring: Analyze crowd density for enhanced security management.
Enhanced Low-Light Performance:
- LightHunter Technology: Provides ultra-high image quality even in low illumination environments.
- True WDR Technology: 120dB true Wide Dynamic Range (WDR) ensures clear images in environments with strong light contrasts.
Flexible Installation:
- Corridor Mode: Support for 9:16 Corridor Mode for optimal viewing in narrow spaces.
- Audio and Alarms: Features 1 audio in/out and 1 alarm in/out for comprehensive monitoring.
Night Vision:
- Smart IR: Infrared capabilities up to 50 meters (164 feet) for clear night-time footage.
Storage and Durability:
- Micro SD Card Support: Compatible with up to 256 GB Micro SD card for local storage.
- Vandal and Weather Resistant: IK10 vandal resistance and IP67 protection ensure durability in harsh conditions.
Power Supply:
- PoE Support: Power over Ethernet (PoE) for simplified installation and power management.
Why Choose the UNIVIEW IPC2325SB-DZK-I0?
This AI IP bullet CCTV camera is designed for those who demand the highest quality in security surveillance. Its advanced features, such as intelligent intrusion prevention and LightHunter technology, provide reliable and precise monitoring day and night. Whether for residential or commercial use, this camera offers robust security with ease of installation and superior performance.
Datasheets
Specifications
Camera
| Feature | Specification |
|---|---|
| Sensor | 1/2.7", 5.0 megapixel, progressive scan, CMOS |
| Minimum Illumination | Colour: 0.002 lux (F1.2, AGC ON); 0 lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| Adjustment Angle | Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360° |
| WDR | 120dB |
| S/N Ratio | >56 dB |
Lens
| Feature | Specification |
|---|---|
| Lens | 2.7 ~ 13.5mm, AF auto focus, motorized zoom |
| Iris | Fixed |
| Field of View (H) | 106.25° ~ 30.42° |
| Field of View (V) | 56.36° ~ 17.22° |
| Field of View (D) | 110.34° ~ 34.18° |
DORI Distance
| Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
|---|---|---|---|---|
| 2.7 | 60.8 | 24.3 | 12.2 | 6.1 |
| 13.5 | 303.8 | 121.5 | 60.8 | 30.4 |
Illuminator
| Feature | Specification |
|---|---|
| IR Range | Up to 50m (164ft) |
| Wavelength | 850nm |
| IR On/Off | Auto/Manual |
Video
| Feature | Specification |
|---|---|
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 Code Profile | Baseline, Main, High |
| Frame Rate (Main Stream) | 5MP (28801620) @30fps, 4MP (25601440) @30fps, 3MP (23041296) @30fps, 1080P (19201080) @30fps |
| Frame Rate (Sub Stream) | 720P (1280720) @30fps, D1 (720576) @30fps, 640*360 @30fps |
| Frame Rate (Third Stream) | D1 (720576) @30fps, 640360 @30fps, 2CIF (704288) @30fps, CIF (352288) @30fps |
| Video Bit Rate | 128 Kbps ~ 16 Mbps |
| U-code | Support |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Up to 8 areas |
| Video Stream | Triple streams |
| Feature | Specification |
|---|---|
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital Noise Reduction | 2D/3D DNR |
| Smart IR | Support |
| Flip | Normal/Vertical/Horizontal/180°/90° Clockwise/90° Anti-clockwise |
| Dewarping | N/A |
| HLC | Support |
| BLC | Support |
| Defog | Digital Defog |
Intelligent Features
| Feature | Specification |
|---|---|
| Smart Intrusion Prevention | Supports false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection |
| Statistical Analysis | People counting, support people flow counting and crowd density monitoring |
Events
| Feature | Specification |
|---|---|
| Basic Detection | Motion detection, Ultra motion detection, Tampering alarm, Audio detection |
| General Functions | Watermark, IP Address filtering, alarm input, alarm output, access policy, ARP protection, RTSP authentication, user authentication |
Audio
| Feature | Specification |
|---|---|
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 64 Kbps |
| Two-way Audio | Support |
| Suppression | Support |
| Sampling Rate | 8KHZ |
Storage
| Feature | Specification |
|---|---|
| Edge Storage | Micro SD, up to 256GB |
| Network Storage | ANR, NAS (NFS) |
Network
| Feature | Specification |
|---|---|
| Protocols | IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS, SSH |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| User/Host | Up to 32 users. 2 user levels: administrator and common user |
| Security | Password protection, strong password, HTTPS encryption, Export operation logs, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
Client
| Feature | Specification |
|---|---|
| EZStation | Support |
| EZView | Support |
| EZLive | Support |
| Web Browser | Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above |
| Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above |
Interface
| Feature | Specification |
|---|---|
| Audio I/O | Input: impedance 35kΩ; amplitude 2V [p-p] |
| Output: impedance 600Ω; amplitude 2V [p-p] | |
| Alarm I/O | 1/1 |
| RS485 | N/A |
| Built-in Mic | N/A |
| Built-in Speaker | N/A |
| WIFI | N/A |
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| Video Output | N/A |
Certifications
| Feature | Specification |
|---|---|
| EMC | CE-EMC (EN 55032: 2015+A1:2020, EN 61000-3-3: 2013+A1: 2019, EN IEC 61000-3-2: 2019+A1: 2021, EN 55035: 2017+A11:2020) |
| FCC (FCC CFR 47 part 15 B, ANSI C63.4-2014) | |
| Safety | CE LVD (EN 62368-1:2014+A11:2017), CB (IEC 62368-1:2014), UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) |
| Environment | CE-RoHS (2011/65/EU; (EU) 2015/863), WEEE (2012/19/EU), Reach (Regulation (EC) No 1907/2006) |
| Protection | IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013), IK10 (IEC 62262:2002) |
General
| Feature | Specification |
|---|---|
| Power | DC 12V±25%, PoE (IEEE 802.3af) |
| Power consumption: Max 8.0 W |
