TP-Link VIGI NVR4016H | 16‑Channel 4K Network Video Recorder, Dual HDMI Output, H.265+ Compression, 4× SATA (Up to 16 TB Each) non PoE

The TP-Link VIGI NVR4016H is a feature-rich 16-channel network video recorder designed to meet the surveillance demands of growing businesses and critical infrastructure. Supporting dual HDMI outputs, independent VGA, and multi-stream viewing, it delivers exceptional flexibility for monitoring and control room installations.

With H.265+ smart compression, up to 320 Mbps bandwidth, and 4× SATA interfaces accommodating up to 64 TB of storage, this NVR ensures seamless recording and storage efficiency. Its advanced decoding capabilities, 16-channel synchronous playback, and dual Ethernet design enable robust performance and redundancy across networks.

📦 What’s Included

• VIGI NVR4016H Unit

• Power Cord

• Mouse

• HDD Power Cables

• HDD Data Cables

• Terminal Blocks

• Mounting Brackets

• Screws

• Rubber Feet

• Installation Guide

⭐ Main Features

• 16-channel IP video input with multi-format recording support up to 8MP

• Dual HDMI output (one 4K) and VGA output for flexible display configurations

• 16-channel synchronous playback for efficient review

• H.265+ Compression Technology maximises storage duration and bandwidth usage

• Dual Gigabit Ethernet ports support redundancy, multi-address mode, and port aggregation

• Smart Video Coding with support for real-time alarms like motion, human, vehicle detection

• Alarm I/O: 16 inputs, 4 outputs for integration with external security systems

• Comprehensive compatibility with ONVIF Profile S and CGI-enabled cameras

• Auto-Initialize feature allows for fast deployment with plug-and-play camera setup

🧩 Detailed Specifications

✅ Warranty & Brand Description

TP-Link’s VIGI NVR4016H is engineered for reliability and performance. With over two decades in the global networking space, TP-Link delivers cutting-edge surveillance systems with local support and warranty services across Australia and New Zealand.

📦 Excellence for the Australian and New Zealand Market

• Meets regional safety and compliance standards (CE, RCM, BSMI, VCCI, etc.)

• Available exclusively via authorized ANZ distributors, ensuring genuine warranty coverage

• Fully compatible with networking standards and climate conditions in Australia and New Zealand

• On-site tech support and local RMA channels ensure minimized downtime for critical deployments

💼 Practical Use Scenarios

• Small to Mid-sized Businesses (SMBs): Secure warehouses, offices, and reception zones with multi-display output

• Educational Institutions: Monitor entry points, parking, and common areas across campuses

• Retail Chains: Track sales floors, storage areas, and POS systems simultaneously

• Healthcare Facilities: Maintain full visibility over patient zones, waiting rooms, and controlled areas

🛠 Installation & Setup

1. Mount unit in rack or secure surface using provided brackets

2. Install up to four 16 TB HDDs using included SATA power/data cables

3. Connect power, network, and display monitors

4. Initiate “Auto Initialize” to configure camera channels and recording schedules

5. Enable alerts, backup, and remote access features via VIGI Security Manager

🔧 SKU

VIGI NVR4016H

📄 Datasheets & Resources

• Product datasheet,

• user manual

❓ FAQs

1. Q: What is the maximum supported storage capacity for the TP-Link VIGI NVR4016H?
   A: It supports up to 64 TB total, across 4 SATA interfaces, each capable of 16 TB.

2. Q: Does the NVR4016H support simultaneous multi-monitor output?
   A: Yes, it has two HDMI ports and one VGA port. However, HDMI2 and VGA cannot function simultaneously.

3. Q: How many channels can be played back at once on the VIGI NVR4016H?
   A: It supports 16-channel synchronous playback, ideal for reviewing footage from multiple cameras in one session.

4. Q: Can this NVR work with third-party IP cameras?
   A: Yes. The VIGI NVR4016H supports ONVIF Profile S and CGI, ensuring broad compatibility.

5. Q: Is the NVR4016H suitable for network redundancy or load balancing?
   A: Yes, it features dual Ethernet ports supporting multi-address, fault tolerance, and port aggregation modes.

6. Q: Is this model covered under local warranty in Australia and New Zealand?
   A: Yes. When purchased through authorized AU/NZ distributors, the VIGI NVR4016H includes full local warranty support.
