TP-Link TL-SG2210MP – JetStream 10-Port Gigabit Smart Managed Switch with 8-Port PoE+

Meet the TP-Link TL-SG2210MP, a powerful JetStream Gigabit Smart Managed Switch designed for small and medium business networks demanding robust performance, advanced security, and PoE flexibility. Featuring 8 Gigabit PoE+ ports and 2 Gigabit SFP slots, it delivers high-speed wired connections and flexible uplinks, perfectly suited for surveillance, wireless, and VoIP deployments.

With a 150W PoE budget, the TL-SG2210MP efficiently powers IP cameras, wireless access points, and other 802.3af/at-compliant devices, reducing the need for separate power supplies and simplifying infrastructure.

Seamlessly integrating with TP-Link’s Omada SDN, this smart switch offers Zero-Touch Provisioning (ZTP), centralized cloud management, and intelligent monitoring for large-scale deployments. Its compact rackmount or desktop-friendly design, along with a rich set of L2/L3 features, ensures that your network remains agile, secure, and scalable.

For businesses seeking reliable Gigabit connectivity with advanced Layer 2+ management and cost-efficient PoE, the TL-SG2210MP is a solid investment in network performance and future growth.

What's Included in the Box

• TL-SG2210MP Switch

• Power Cord

• Installation Guide

• Rackmount Kit

• Rubber Feet

Main Features

✅ Full Gigabit Connectivity

• 8× Gigabit PoE+ ports and 2× SFP slots deliver high-speed, reliable connections for network devices and uplinks.

✅ 150W PoE Budget

• Easily powers IP cameras, wireless APs, or VoIP phones with up to 30W per port.

✅ Omada SDN Integration

• Enables cloud-based management, Zero-Touch Provisioning (ZTP), and remote monitoring (not supported on v2 hardware).

✅ Robust Security Suite

• Protects your network with IP-MAC-Port Binding, ACLs, 802.1X, DoS Defend, DHCP Snooping, and more.

✅ Optimized for Voice and Video Traffic

• L2/L3/L4 QoS, IGMP Snooping, and multicast management ensure smooth streaming and minimal latency.

✅ Versatile Deployment Options

• Fan-assisted cooling for reliable performance, with rackmount or desktop installation.

Detailed Specifications

Hardware Specifications

• Ports:

  • 8× 10/100/1000 Mbps RJ45 Ports (PoE+ capable)

  • 2× 100/1000 Mbps SFP Slots

• PoE Standard: IEEE 802.3af/at

• PoE Power Budget: 150 W

• Physical Security Lock: Yes

• Fan Quantity: 1

• Mounting: Rackmount/Desktop

• Dimensions: 11.6 x 7.1 x 1.7 in (294 x 180 x 44 mm)

• Max. Power Consumption:

  • Up to 175.3 W depending on hardware version with full PoE load

• Max. Heat Dissipation:

  • Up to 597.8 BTU/hr (110 V/60 Hz with 150 W PD connected)

Performance

• Switching Capacity: 20 Gbps

• Packet Forwarding Rate: 14.9 Mpps

• MAC Address Table: 8K

• Packet Buffer Memory: 4.1 Mbit

• Jumbo Frame: 9 KB

Software Features

• Quality of Service (QoS):

  • 8 Priority Queues

  • Strict Priority (SP), Weighted Round Robin (WRR)

  • Bandwidth Control (Port/Flow based)

  • Storm Control (broadcast/multicast/unicast)

• Layer 2 & Layer 2+ Features:

  • Static Link Aggregation and LACP

  • Spanning Tree Protocol (STP/RSTP/MSTP)

  • Loopback Detection

  • Port Mirroring

  • 802.1x Flow Control

• Layer 3 Features:

  • Static Routing (IPv4/IPv6)

  • DHCP Relay, DHCP L2 Relay

• L2 Multicast:

  • IGMP v1/v2/v3 Snooping

  • IGMP Fast Leave

  • MLD Snooping v1/v2

  • Multicast VLAN Registration (MVR)

• VLAN:

  • Up to 4K VLAN groups

  • MAC VLAN

  • Protocol VLAN

  • GVRP

  • Voice VLAN

• Access Control:

  • Time-Based ACL

  • MAC/IP/IPv6 ACL

  • Combined ACL

  • Up to 230 ACL entries

• Security:

  • 802.1X authentication

  • AAA (TACACS+/RADIUS)

  • IP-MAC-Port Binding

  • DHCP Snooping

  • DoS Defend

  • Port Isolation

• IPv6:

  • Dual Stack IPv4/IPv6

  • IPv6 ACLs

  • Neighbor Discovery

  • ICMPv6

  • Static IPv6 Routing

• Management:

  • Omada SDN (Cloud, OC200, OC300, Software Controller)

  • Web UI, CLI via Telnet/SSH

  • SNMP v1/v2c/v3

  • RMON

  • Dual Image support

  • CPU Monitoring

  • Cable Diagnostics

Warranty Information

TP-Link offers standard limited warranty coverage for the TL-SG2210MP. Warranty terms may vary by region. Businesses are encouraged to register their device for streamlined support and potential firmware updates.

About TP-Link Omada

TP-Link Omada delivers a unified, scalable networking platform designed for modern businesses. Integrating switches, gateways, and wireless APs under one central controller, Omada provides exceptional reliability, security, and cost efficiency.

SKU

TL-SG2210MP

Practical Use Scenarios

• Small Business Networks: Deploy PoE to power IP cameras, VoIP phones, and Wi-Fi access points without extra electrical wiring.

• Retail Environments: Power POS devices and surveillance cameras while maintaining high-speed backbone connectivity.

• Offices: Quiet operation and rackmount flexibility make it ideal for small server rooms or IT closets.

• Hospitality: Simplify network deployment in hotels or restaurants with Omada SDN integration.

Datasheets or Downloadable Resources

Download TL-SG2210MP Datasheet

Excellence for the Australian and New Zealand Market

The TL-SG2210MP meets CE, FCC, and RoHS standards, ensuring compliance and quality for businesses in Australia and New Zealand. Customers benefit from purchasing through authorized channels for legitimate warranty support and local service. For new deployments, consider verifying compatibility with current Omada SDN platforms, as specific hardware versions (e.g. v2) may lack cloud controller support.

FAQs (TL-SG2210MP)

Q1: Does the TL-SG2210MP support PoE on all ports?
A1: No. The TL-SG2210MP provides PoE+ on ports 1–8, with a total budget of 150 W. Ports 9 and 10 are SFP uplinks and do not support PoE. (TL-SG2210MP)

Q2: Can I manage the TL-SG2210MP through the Omada Cloud Controller?
A2: Yes, except for the v2 hardware version which does not support Omada Cloud Controller. Versions v1, v3, and newer are cloud-compatible. (TL-SG2210MP)

Q3: What’s the switching capacity of TL-SG2210MP?
A3: The switch delivers a switching capacity of 20 Gbps and a forwarding rate of 14.9 Mpps. (TL-SG2210MP)

Q4: Is the TL-SG2210MP fanless?
A4: No. The switch has one fan for active cooling to support PoE loads and ensure stability. (TL-SG2210MP)

Q5: Does the TL-SG2210MP support IPv6?
A5: Yes. It supports IPv6 static routing, neighbor discovery, IPv6 ACLs, and various IPv6 management features for future-proof networks. (TL-SG2210MP)
