TP-Link TL-SF1016 | 16-Port 10/100Mbps Rackmount Ethernet Switch | Energy-Efficient | Fanless | Plug & Play

e TP-Link TL-SF1024D is a compact, energy-efficient 24-Port 10/100Mbps Ethernet Switch ideal for small business networks and home offices. Designed to optimize wired connectivity with high reliability, the TL-SF1024D provides plug-and-play functionality with auto MDI/MDIX support to eliminate crossover cable concerns.

Housed in a durable 13-inch steel desktop/rackmount case, it’s a perfect fit for desktop deployments or standard rack installations. Featuring MAC address self-learning, store-and-forward switching, and IEEE 802.3x flow control, it ensures efficient and consistent data traffic handling.

Thanks to TP-Link Green Ethernet technology, the switch delivers up to 75% power savings, helping you minimize your energy bills while keeping your network performance intact.

What's in the Box

• TL-SF1024D 24-Port 10/100Mbps Desktop/Rackmount Switch

• Power Adapter

• Installation Guide

• Rackmount Kit

• Rubber Feet

Main Features

✅ 24× 10/100 Mbps RJ45 Ports with auto-negotiation and auto MDI/MDIX
✅ Green Ethernet technology — reduces power usage by up to 75%
✅ Fanless design — silent and energy-efficient operation
✅ MAC address auto-learning & aging
✅ IEEE 802.3x flow control — for reliable full-duplex transmission
✅ Store-and-forward architecture — minimizes packet errors
✅ Standard 13-inch steel case — rack or desktop mountable

Detailed Specifications

Hardware Features

• Standards & Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

• Interfaces: 24 × 10/100 Mbps RJ45 ports (Auto Negotiation / Auto MDI/MDIX)

• Network Media:

  • 10BASE-T: UTP Cat 3/4/5 (max 100m)

  • 100BASE-TX: UTP Cat 5/5e or higher (max 100m)

• Power Supply: External Adapter (Output: 9VDC / 0.6A)

• Max Power Consumption: 3.19W

• Max Heat Dissipation: 10.88 BTU/h

• Fan Quantity: Fanless

• Physical Security Lock: Yes

• Mounting: Desktop or Rackmount

• Dimensions: 11.6 × 7.1 × 1.7 in (294 × 180 × 44 mm)

Performance

• Switching Capacity: 4.8 Gbps

• Packet Forwarding Rate: 3.57 Mpps

• MAC Address Table: 8K entries

• Buffer Memory: 2 Mb

• Transmission Method: Store-and-Forward

Warranty Information

The TL-SF1024D is backed by TP-Link's limited warranty, with full support provided through authorized distributors in Australia and New Zealand.

Brand Description

TP-Link is a globally recognized leader in networking equipment, offering high-performance, budget-friendly, and energy-conscious solutions. With strong representation in the ANZ region, TP-Link ensures local support and availability across all major industries and households.

SKU

TL-SF1024D

Practical Use Scenarios

• 🏢 Business Offices – Power network infrastructure across employee workstations

• 🏘️ Apartment Buildings – Manage wired connections across units cost-effectively

• 🧑🏫 Education Institutions – Centralized switching for classroom or lab computers

• 🧰 Workshops/Studios – Expand wired networks for high-reliability hardware setups

• 📦 Warehouses – Enable device connectivity for inventory and logistics systems

Datasheets / Downloadable Resources

TP-Link TL-SF1024D

Excellence for the Australian and New Zealand Market

The TL-SF1024D is fully compatible with Australian and New Zealand power standards, and RCM-certified for local safety compliance. Stocked and distributed by authorized local resellers, it ensures dependable delivery, warranty handling, and post-purchase support within the region.

 FAQs

Q1. Can the TL-SF1024D be rack-mounted? (TL-SF1024D)
Yes, the TL-SF1024D comes with rackmount brackets and is designed for standard 13-inch rackmount installation.

Q2. Is TL-SF1024D a managed switch? (TL-SF1024D)
No, the TL-SF1024D is an unmanaged switch and does not require configuration.

Q3. Does TL-SF1024D support Gigabit Ethernet? (TL-SF1024D)
No, the TL-SF1024D supports 10/100 Mbps speeds and is best suited for basic Ethernet applications.

Q4. How does Green Ethernet technology work in TL-SF1024D? (TL-SF1024D)
Green Ethernet automatically adjusts power consumption based on link status and cable length, reducing power usage by up to 75%.

Q5. What is the ideal use case for TL-SF1024D? (TL-SF1024D)
TL-SF1024D is ideal for environments requiring stable 10/100 Mbps LAN connectivity without advanced configuration — such as small offices, schools, or utility room
