Satellite Siren & Strobe Combination Unit with Backup Battery – Hardwired Alarm Siren | WP06SS

The WP06SS Satellite Siren & Strobe Combination Unit is a reliable hardwired alarm signalling device designed for security alarm systems requiring both audible and visual alerts. Featuring a powerful 100dB siren output and LED strobe indicators, this unit ensures clear alarm notifications during security events while acting as a strong visual deterrent.

Designed with a built-in rechargeable lithium backup battery, the WP06SS siren strobe unit continues to operate even if external power is interrupted. The device includes adjustable siren cut-off timers, dual LED status indicators, and tamper protection, ensuring dependable operation in residential and commercial alarm installations. Its durable rectangular housing with rounded ends allows easy wall mounting and professional installation.

What’s Included in the Box

• Satellite Siren & Strobe Unit – WP06SS

• Built-in Rechargeable Battery


Main Features

• Combined Siren & Strobe Alarm Unit – Provides both audible and visual alarm alerts.

• 100dB Siren Output – Strong internal alarm signal for security events.

• Built-in Rechargeable Backup Battery – Maintains operation during power loss.

• Adjustable Siren Cut-Off Timer – Selectable cut-off times for alarm duration.

• Dual LED Status Indicators – Displays alarm status and charging condition.

• Hardwired Alarm Integration – Designed for connection to standard alarm panels.

• Durable Rectangular Housing – Robust casing suitable for security installations.

Detailed Specifications

Alarm Output

• Sound pressure level: 100dB at 100 cm

Electrical

• Operating voltage: 9–30V DC

• Siren current consumption: 120mA

• Strobe current consumption: 50mA

• Battery charging current: 50mA

Backup Battery

• Built-in Lithium rechargeable battery

• Battery specification: 3.7V 750mAh

Visual Indicators

• Red LED – Alarm indicator (pulses during standby, solid during alarm)

• Green LED – Battery charging indicator

Adjustable Settings

• Siren cut-off timer: selectable 2, 5, or 10 minutes

Physical Specifications

• Dimensions: 200 × 115 × 75 mm

• Housing style: Rectangular with rounded ends

Wiring Terminals

• +12V DC

• Siren input

• Strobe input

• Tamper return

• Spare terminal

The terminal block diagram and wiring layout are shown on the installation sheet.

Practical Use Scenarios

• Residential Security Systems – Audible and visual alarm notification for homes.

• Commercial Premises – Visible deterrent and alarm signalling device.

• Warehouse Security Installations – Loud alerts for larger indoor areas.

• Alarm Panel Installations – Hardwired siren with backup battery protection.

• Security System Upgrades – Adds strobe visibility and battery backup to existing systems.

Warranty

Manufacturer Warranty – 12 Months

Brand Overview

The WP06SS satellite siren is designed for professional security alarm installations, providing dependable audible alerts, visual alarm indication, and backup battery operation. With adjustable siren timing and status indicators, it delivers reliable alarm signalling for modern security systems.

Datasheets & Resources

• Installation, Testing & Operation Guide


Excellence for the Australian and New Zealand Market

This product is supplied specifically for the Australian and New Zealand security market, ensuring compatibility with commonly used hardwired 12V alarm systems in the region. Products are sourced through authorised distributors, providing reliable warranty support and professional installer compatibility.

SKU

WP06SS

FAQs

What is the WP06SS siren strobe unit used for?

The WP06SS is a hardwired alarm signalling device that provides both audible siren alerts and flashing strobe indication during alarm events.

Does the WP06SS have a backup battery?

Yes. The WP06SS includes a built-in rechargeable 3.7V lithium battery to maintain operation if external power is lost.

How loud is the WP06SS siren?

The WP06SS produces a sound level of approximately 100dB at 100 cm, providing strong audible alarm signalling.

What voltage does the WP06SS operate on?

The WP06SS operates on 9–30V DC, making it compatible with most standard alarm control panels.

Can the alarm duration be adjusted on the WP06SS?

Yes. The WP06SS includes an adjustable siren cut-off timer that can be set to 2, 5, or 10 minutes.

What do the LEDs on the WP06SS indicate?

The WP06SS includes two status LEDs:

• Red LED – indicates alarm status

• Green LED – shows battery charging status.
