Ruijie Reyee RG-RAP2260(G) Reyee Wi-Fi 6 AX1800 Ceiling Access Point

The Reyee RG-RAP2260(G) Wi-Fi 6 AX1800 Ceiling Access Point is an advanced networking solution designed to deliver ultra-fast and reliable wireless performance for modern businesses and high-density environments. Leveraging Wi-Fi 6 (802.11ax) technology, it offers enhanced speed, greater client capacity, and seamless connectivity, meeting the demands of the most demanding applications.

With its Reyee Mesh Technology, the RG-RAP2260(G) simplifies network expansion without complex wiring. The Ruijie Cloud APP enables quick and intuitive setup, allowing a complete Wi-Fi 6 network to be established in just 3 minutes. With a client capacity of up to 512 devices, this access point ensures an exceptional user experience in high-density scenarios, making it ideal for offices, educational institutions, and public venues.

The sleek ceiling-mounted design integrates seamlessly into any environment, while the CE and RoHS certifications underscore its commitment to quality and environmental standards.

What’s Included in the Box

• 1x Reyee RG-RAP2260(G) Wi-Fi 6 Ceiling Access Point
• Mounting Kit
• Quick Installation Guide

Main Features

• Wi-Fi 6 Technology: Achieve faster speeds and improved efficiency for high-density environments.
• High Client Capacity: Support up to 512 devices, with optimized performance for 100 recommended clients.
• Reyee Mesh Technology: Simplify expansion and reduce wiring with a mesh-enabled network.
• Quick Setup: Configure your Wi-Fi 6 network in just 3 minutes via the Ruijie Cloud APP.
• Superior Throughput: 745 Mbps transmit and 751 Mbps receive speeds for 5GHz, outperforming competitors like Ubiquiti U6-Lite and Aruba AP22.
• Cloud Management: Access centralized network management, remote monitoring, and scenario-based configurations.
• Environmentally Certified: CE and RoHS certifications for safety and eco-friendliness.

Detailed Specifications

• Wireless Protocol: 802.11ax (Wi-Fi 6), AX1800 (1775 Mbps)
• Network Ports: 2 x 10/100/1000 Base-T Ethernet ports
• Antenna: Built-in Omni-directional
• MIMO: 2x2 @ 2.4GHz, 2x2 @ 5GHz
• Max/Recommended Clients: 512 / 100
• Operating Temperature: 0°C ~ 40°C
• Power Supply: 802.3at PoE or 12V/1.5A DC Adaptor
• Power Consumption: <15.3W
• Certifications: CE, RoHS
• Dimensions: 194mm × 194mm × 35mm
• Weight: 0.56kg (excluding mounting kits)
• Warranty: 3 Years

Warranty Information

The Reyee RG-RAP2260(G) includes a 3-year warranty, ensuring dependable service and peace of mind.

Brand Description

Reyee by Ruijie Networks is a leader in networking solutions, committed to providing reliable, high-performance, and user-friendly products. Designed with cutting-edge technology, Reyee products cater to the needs of businesses, schools, and other enterprises.

SKU

RG-RAP2260-G

Practical Use Scenarios

• Offices and Businesses: High-speed connectivity and capacity for multiple users.
• Educational Institutions: Seamless connectivity for students and staff in classrooms or campus-wide.
• Public Venues: Reliable performance in high-density settings such as conference halls, malls, and airports.
• Hospitality: Enhanced guest Wi-Fi experience in hotels and resorts.

Excellence for the Australian and New Zealand Market

The Reyee RG-RAP2260(G) is specifically tailored for the Australian and New Zealand market, offering:

• Compliance with Australian quality standards and certifications.
• CE and RoHS certified for safe and eco-friendly operations.
• Optimized performance to handle high-density environments typical in ANZ.
• Exclusive sourcing from authorized representatives ensures authenticity.
• Simplified warranty handling directly with the brand, ensuring reliable post-purchase support.
