Ruijie Reyee RG‑RAP2200(F) WiFi 5 AC1300 Dual‑Band Ceiling Access Point – 1267 Mbps, Cloud‑Managed for Enterprise, Education, Hospitality & Retail

The Ruijie Reyee RG‑RAP2200(F) is a high‑performance indoor ceiling‑mount WiFi access point designed for demanding enterprise, education, government, retail and hospitality environments across Australia and New Zealand. With dual‑radio operation, IEEE 802.11ac Wave2 technology including MU‑MIMO, and free cloud‑based management via the Ruijie Cloud platform, this AP provides robust, scalable, easy‑to‑deploy wireless coverage in high‑density scenarios.

From seamless Layer‑3 roaming to “one‑click” WiFi intelligent optimisation (WIO) and rapid deployment via the Ruijie Cloud App, the RG‑RAP2200(F) ensures high‑speed wireless access, simplified administration and reliable real‑world performance — all with the lowest total cost of ownership. Whether you’re outfitting classrooms, conference rooms, multi‑story hotels or retail floors, this ceiling AP gives you enterprise‑grade features without requiring a controller on‑site.

What’s Included in the Box

• Ruijie Reyee RG‑RAP2200(F) access point

• Mounting bracket (ceiling/wall)

• 2 × cross pan‑head screws

• 2 × expansion anchors

• Quick Start Guide

• Warranty card

Main Features

• Dual‑radio architecture (2.4 GHz + 5 GHz) delivering combined throughput of up to 1.267 Gbps (400 Mbps @2.4GHz + 867 Mbps @5GHz)

• IEEE 802.11ac Wave 2 support including 2×2 MU‑MIMO, offering superior performance in multi‑user, high‑density environments

• Seamless Layer 3 roaming enables uninterrupted connectivity across different subnets — ideal for large campus‑style deployments

• Built‑in WIO (“WiFi Intelligent Optimisation”) feature supports one‑click wireless network optimisation for simplified maintenance and improved experience

• Rapid deployment through the Ruijie Cloud App and SON (Self‑Organising Network) technology — set up in around 3 minutes and manage remotely, reducing installation and management overhead

• Free lifetime cloud management via Ruijie Cloud platform — remote monitoring, firmware upgrades, scenario‑based config, central management

• Two up‑link Ethernet ports (model dependent) for flexibility — RG‑RAP2200(F) uses dual 10/100 Mbps uplinks

• Ceiling‑ or wall‑mountable design, compact (194 mm × 194 mm × 35 mm) and lightweight (≤ 0.45 kg) for easy installation

Detailed Specifications

Warranty Information

Provided by the manufacturer Ruijie Networks via authorised Australian/NZ distribution. Warranty card is included in the box.

Brand Description

Ruijie Networks is a global networking equipment provider specialising in enterprise‑grade solutions for wireless, switching and cloud‑managed networks. The Reyee series is designed to offer scalable, cloud‑managed connectivity solutions suitable for education, hospitality, retail and enterprise deployments — combining robust features with simplified deployment and management.

SKU

RG‑RAP2200F‑AU/NZ

Practical Use Scenarios

• University lecture theatre or campus buildings: With its 2×2 MU‑MIMO and up to 110 simultaneous clients per band, the RG‑RAP2200(F) excels in high‑density environments where many students connect at once.

• Hotel lobby or guest‑access floors: Utilise cloud management and SSID segmentation (guest / staff) for ease of deployment; seamless roaming supports guests moving between floors/subnets.

• Retail flagship store: Ceiling‑mount design blends into modern interiors; dual‑uplink port enables linking to PoE cameras or digital signage alongside WiFi.

• Government office or branch offices: Layer 3 roaming supports distributed networks; remote cloud management allows centralised administration of multiple sites.

Datasheets / Downloadable Resources

• Datasheet: “RG‑RAP2200 Series Reyee WiFi 5 AC1300 Indoor Cloud Managed Access Point” (PDF)


Excellence for the Australian and New Zealand Market

• Sourced exclusively from authorised Ruijie Networks distributors ensuring genuine product and full local compliance

• Meets relevant Australian standards for telecommunication and network hardware

• Free lifetime Ruijie Cloud management — ideal for Australian/NZ multi‑site deployments where remote administration is key

• Warranty support available via local distribution and servicing channels — tailored for Australia and New Zealand customers

• Designed for environments common in ANZ: education campuses, chain retail stores, hospitality venues — delivering high‑density wireless performance with minimal overhead

FAQs

Q1: What is the maximum throughput of the RG‑RAP2200(F)?
A1: The product code RG‑RAP2200F supports up to approximately 1.267 Gbps combined throughput (400 Mbps on 2.4 GHz + 867 Mbps on 5 GHz) under ideal conditions.

Q2: Does the RG‑RAP2200(F) support cloud management?
A2: Yes, the RG‑RAP2200F supports lifetime free management via the Ruijie Cloud platform.

Q3: Can the RG‑RAP2200(F) be used in a high‑density client environment like a classroom or lecture theatre?
A3: Absolutely — the RG‑RAP2200F is designed for high‑density scenarios and supports up to 110 clients in combined mode.

Q4: Does the RG‑RAP2200(F) support PoE?
A4: Yes — the RG‑RAP2200F supports IEEE 802.3af/at PoE or DC 12 V / 1.5 A local power supply.

Q5: Is the RG‑RAP2200(F) suitable for Australian/NZ compliance and warranty support?
A5: Yes — when sourced via authorised channels for Australia and New Zealand, the RG‑RAP2200F meets required standards and is covered under local warranty support.
