POE10E | Omada Fast Ethernet PoE+ Extender | 802.3af/at Compliant | Up to 250m Range

Extend your PoE network’s reach effortlessly with the TP-Link POE10E Omada Fast Ethernet PoE+ Extender. Designed to boost the flexibility of PoE deployment, the POE10E adds an additional 100 to 250 metres of both power and data transmission to your network — all with a plug-and-play setup that requires zero configuration.

Engineered for compatibility with IEEE 802.3af/at compliant devices, this compact yet powerful extender supports power delivery of up to 20W, ideal for IP cameras, VoIP phones, and wireless access points. Whether for long corridors, outdoor setups, or expansive installations, the POE10E simplifies the process of powering devices far from power outlets or switches.

What's in the Box

• TP-Link POE10E Fast Ethernet PoE+ Extender

• Installation Guide

Main Features

✅ Complies with IEEE 802.3af/at standards – Ensures wide device compatibility
✅ 2× 10/100 Mbps RJ45 Ports – One PoE IN, one PoE OUT
✅ Extends PoE power & data transmission by 100–250 meters
✅ Up to 20W power output – Perfect for most PoE-powered IP cameras
✅ Plug-and-Play – No software setup or configuration required
✅ Compact & lightweight form factor – Easy to integrate into tight spaces
✅ Fanless, silent operation

Detailed Specifications

Interfaces

• 1× 10/100 Mbps RJ45 PoE IN Port

• 1× 10/100 Mbps RJ45 PoE OUT Port (up to 20 W)

Supported Media

• UTP/STP of Cat.5e or above (based on device standards)

Standards and Protocols

• IEEE802.3i, IEEE802.3u

• IEEE802.3af/at compliant

Key Functions

• PoE/PoE+ extension range:

  • Up to 100 m at 100 Mbps

  • Up to 250 m at 10 Mbps mode

• Auto power detection and delivery

• Passive, unmanaged design

Dimensions

• 2.33 × 0.85 × 0.52 in (71 × 26 × 16 mm)

Warranty Information

Manufactures warrenty applied

Brand Description

TP-Link Omada is a leading name in enterprise-grade and SMB networking. Built on reliability, efficiency, and performance, Omada devices such as the POE10E extend the brand’s value by offering scalable, intelligent network power solutions that are both cost-effective and easy to deploy.

SKU

POE10E

Practical Use Scenarios

📹 Extend PoE for outdoor security cameras mounted far from the switch
🏢 Power VoIP phones in large office spaces without rewiring
📡 Deploy wireless access points in remote corridors or parking areas
🏠 Integrate smart devices at extended distances in large homes
🏫 Use in schools or industrial zones for powering networked equipment across buildings

Datasheets / Downloadable Resources

• Technical POE10E datasheet

Excellence for the Australian and New Zealand Market

The POE10E meets strict FCC, CE, and RoHS certifications and is built to meet Australian and New Zealand safety standards. This model is officially sourced from TP-Link’s authorized ANZ distributor network, ensuring direct local support for any warranty claims or technical issues. The extender is ideal for long-range deployments where high-performance networking and NDSS-compliant installations are crucial.

 FAQs

Q1. What devices can the POE10E support? (POE10E)
The POE10E supports all IEEE 802.3af/at compliant devices, such as IP cameras, wireless access points, and VoIP phones.

Q2. How far can the POE10E extend a PoE network? (POE10E)
It can extend a PoE/PoE+ network by up to 100 meters at 100 Mbps or 250 meters at 10 Mbps.

Q3. Does the POE10E require any configuration or software? (POE10E)
No. The POE10E is completely plug-and-play and does not require any configuration or software.

Q4. What is the maximum power output of the POE10E? (POE10E)
The POE10E provides up to 20W output, which is sufficient for most standard PoE and PoE+ devices.

Q5. Is the POE10E suitable for outdoor installations? (POE10E)
The POE10E itself is not weatherproof and should be installed in a protected indoor environment, even if extending to an outdoor device.
