Easy installation with DirectIP NVR integration
-
8 MP (3840 × 2160) ultra-high-definition resolution
-
Motorized vari-focal lens (f = 2.7 – 13.5 mm) for remote zoom and focus control
-
True WDR (120 dB) ensures balanced imaging in high-contrast lighting conditions
-
Day and Night (ICR) with smart IR LEDs (6 pcs, up to 40 m / 131 ft) illumination
-
micro SD/SDHC/SDXC support with Smart Failover for continuous recording
-
Two-way audio (built-in mic and external speaker connection)
-
Alarm input/output for system integration
-
Built-in heater for reliable operation in cold environments
-
Rugged outdoor design: IP67 weatherproof & IK10 vandal-resistant housing
-
Power options: PoE (IEEE 802.3af Class 3) or 12 V DC
-
3-axis mechanical design for flexible installation and precise alignment
-
ONVIF compliant, ensuring interoperability with third-party systems
-
NDAA compliant for government-approved projects
Technical Specifications
| Category | Details |
|---|---|
| Image Sensor | 1/2.8" CMOS |
| Maximum Resolution | 3840 × 2160 (8 MP) |
| Lens | Motorized vari-focal, f = 2.7 – 13.5 mm / F1.8 – 3.32 |
| Field of View | Horizontal 110.6° – 32.6° / Vertical 57.3° – 18.3° |
| Minimum Illumination | Color: 0.2 lux @ F1.8 B/W: 0 lux (IR on) |
| IR Range | Up to 40 m (131.2 ft) |
| WDR | True 120 dB |
| Video Compression | H.265 / H.264 / MJPEG |
| Frame Rate | 30 fps @ 8 MP (15 fps with WDR) |
| Audio | Two-way audio, G.711 u/a, G.726, ADPCM 16 K |
| Alarm I/O | 1 input / 1 output |
| Storage | micro SD/SDHC/SDXC (up to 256 GB) with Smart Failover |
| Network Protocols | DirectIP 2.0, ONVIF Profile S/T, IPv4/IPv6, RTSP, HTTPS, SSL, IEEE 802.1x |
| Power Supply | PoE (IEEE 802.3af Class 3) / 12 V DC |
| Power Consumption | Max. 13.2 W (DC) / 11.7 W (PoE) |
| Operating Temperature | –40 °C to +55 °C (start-up above –20 °C) |
| Ingress Protection | IP67 / IK10 |
| Dimensions (W × H × D) | 80 × 75 × 237 mm |
| Weight | Approx. 1.01 kg |
