Hanwha Wisenet CT-QRN-430S Q Series NVR, 4CH 8MP with PoE switch, NDAA compliant by Samsung

Hanwha Wisenet CT-QRN-430S Q Series NVR, 4CH 8MP with PoE switch, NDAA compliant by Samsung

$481.44 AUD
$712.98 AUD $481.44 AUD
Sale Sold out
Duties and taxes included. Shipping calculated at checkout.

The Hanwha Vision Q Series HV‑QRN‑430S is an entry‑level network video recorder (NVR) designed for small to medium surveillance setups. It offers core features in a compact form, enabling simple, reliable, high‑definition recording and monitoring for retail, small offices, branches, and light commercial applications.

What’s Included in the Box

  • 1 × HV‑QRN‑430S NVR (no HDD included) (Choose your own HDD below)

  • 1 × Power adapter / DC cable

  • 1 × USB mouse

  • Mounting bracket / rack ears

  • Quick Start Guide and documentation

  • Screws for HDD installation

Main Features

  • Supports up to 4 IP cameras (4CH) at resolutions up to 8MP

  • Video compression: H.265, H.264, MJPEG

  • Incoming bandwidth up to 40 Mbps

  • 4 built‑in PoE ports (plug‑and‑play for PoE cameras)

  • 1 × SATA bay, supports up to 6 TB HDD

  • Local display via HDMI (max UHD/4K)

  • P2P connectivity utilizing QR code for remote setup

Detailed Specifications

Feature Specification
Model / SKU HV‑QRN‑430S / QRN‑430S
Camera Inputs Up to 4 channels
Supported Resolution 8MP down to CIF
Decoding / Display HDMI — 8M@30fps, 1080p@120fps, 720p@120fps, D1@120fps
Compression / Codecs H.265, H.264, MJPEG
Recording Bandwidth Max 40 Mbps
Recording Modes Normal, Dual‑stream, Schedule (continuous/event), Event (pre + post)
Event Triggers Alarm input, video loss, motion detection, analytics, defocus, audio
Action on Event Email, push notification, PTZ preset, alarm out, buzzer, monitor out
Playback / Search Multi‑channel playback, bookmark, timeline, date/time, event filters
Simultaneous Users 4 users (1 local, 3 remote)
Playback Bandwidth Max 32 Mbps
PoE / Ethernet 4 × PoE (10/100) + 1 × LAN (10/100)
USB Ports 2 × USB 2.0 (front + rear)
Storage 1 × SATA bay, up to 6 TB
Backup Options Via GUI (BU/Exe), Network (JPG/AVI)
Local Output HDMI 3840 × 2160 @ 30 Hz
Power Input 100~240 VAC, 50/60 Hz
Power Consumption Max 52 W (with HDD + PoE)
PoE Budget 35 W total
Operating Temperature 0 °C to +40 °C
Humidity Range 20% to 85% RH
Dimensions 300.0 × 47.1 × 208.4 mm
Weight ~1.03 kg
Protocols IPv4, IPv6, TCP/IP, UDP, RTSP, HTTP, SMTP, SNMP, ONVIF, SUNAPI etc.
Security / Features IP filtering, user access logs, 802.1x, device certificates, signed firmware
Supported Software / Apps WAVE, SSM, WebViewer, Smart Viewer, mobile (iOS, Android)

Note: Design and specifications are subject to change without notice by Hanwha.

Datasheets

Manual
Data Sheet
Brochure

Warranty & Support

Check with your distributor for warranty coverage in your region. Hanwha typically offers manufacturer warranties (often 2–3 years) on their NVR hardware. Ensure the unit is registered via authorized channels for warranty validity.

Practical Use Scenarios

  • Small retail store / shop: monitor 4 entry/exit points or interior zones.

  • Branch office / corporate site: record key areas like reception, server room, lobby.

  • ATM / kiosk booths: with up to 8MP cameras, capture finer detail (license plates, faces).

  • Remote sites: leverage the P2P QR code setup for fast remote access setup.

  • Mixed resolution systems: integrate older lower-res cameras in the same NVR.

Excellence for the Australian & New Zealand Market

  • Supplied via authorized Hanwha / Wisenet distributors in ANZ

  • Meets relevant local standards (voltage compatibility, safety)

  • Warranty and service handled locally for faster support

  • Optimised for regional network conditions (e.g. wide area remote links, P2P)

  • Local installers and integrators experienced with this line
