Hanwha Vision Wisenet X-Series HV-XNV-6012 2MP External Vandal Dome Camera – Fixed 2.4mm Lens, 150dB WDR, IP66/IK10/NEMA4X | SKU: HV-XNV-6012x series

Hanwha Vision Wisenet X-Series HV-XNV-6012 2MP External Vandal Dome Camera – Fixed 2.4mm Lens, 150dB WDR, IP66/IK10/NEMA4X | SKU: HV-XNV-6012x series

$871.08 AUD
$1,212.78 AUD $871.08 AUD
Sale Sold out
Duties and taxes included. Shipping calculated at checkout.

[Special Order Item: May take longer for product to be posted]

The Hanwha Vision HV-XNV-6012 Wisenet X-Series 2MP External Vandal Dome Camera delivers powerful video surveillance performance in a compact, rugged form factor. Featuring a 2MP CMOS sensor and a wide-angle 2.4mm fixed lens, this camera offers a generous horizontal field of view of 135.4°, making it ideal for broad coverage in outdoor environments such as transportation hubs, building perimeters, and public spaces.

Engineered for clarity in all lighting conditions, the camera supports up to 150dB WDR, ensuring clear images even in scenes with intense backlighting or shadows. Low-light performance is impressive, with color sensitivity down to 0.04 Lux and enhanced digital noise reduction via SSNRⅤ technology.

Despite its compact size, the camera packs advanced features:

  • Analytics support for motion detection, face detection, tampering, loitering, virtual line crossing, and more.

  • Multiple streaming capabilities supporting up to 10 profiles for optimized bandwidth usage.

  • Durable construction, rated IP66/IP67, IK10, and NEMA4X, ready for harsh outdoor conditions.

Perfect for projects requiring high-quality imaging in tight spaces, the HV-XNV-6012 is a cost-effective yet sophisticated addition to professional surveillance systems.

What’s Included in the Box

  • Hanwha Vision HV-XNV-6012 Wisenet X-Series Dome Camera

  • Installation hardware

  • Quick Installation Guide

Main Features

  • 2MP CMOS sensor for crisp 1920 × 1080 resolution video.

  • 2.4mm fixed lens with ultra-wide 135.4° horizontal field of view.

  • Supports H.265, H.264, and MJPEG codecs for flexible streaming.

  • 150dB WDR for excellent image clarity under challenging lighting.

  • Low-light capability down to 0.04 Lux (Color).

  • Advanced video analytics:

    • Motion detection

    • Face detection

    • Tampering detection

    • Virtual line crossing

    • Fog detection

    • Audio detection

  • Built-in microSD slot (up to 256GB) for edge recording.

  • PoE powered for simplified installation.

  • Compact form factor for discreet deployment.

  • Rugged design with IP66, IK10, NEMA4X protection.

Detailed Specifications

Category Details
Image Sensor 1/2.8” 2MP CMOS
Effective Pixels 1945 (H) × 1079 (V)
Max Resolution 1920 × 1080
Frame Rate Max. 60 fps (H.265/H.264)
Lens Fixed 2.4mm, F2.0
Field of View H: 135.4°, V: 71.2°, D: 161.6°
Min. Illumination Color: 0.04 Lux, B/W: 0.004 Lux
IR Illumination No built-in IR LEDs
Video Compression H.265, H.264 (Main, Baseline, High), MJPEG
Audio Compression G.711, G.726, AAC-LC
Edge Storage microSD/SDHC/SDXC up to 256GB
Pan/Tilt/Rotate Range -5°~5° / 0°~67° / -90°~90°
Analytics Motion, face, tampering, fog, directional detection, audio detection, virtual line, loitering, appear/disappear
Network Interface RJ-45 (10/100BASE-T)
Protocols IPv4/IPv6, HTTPS, SNMP v1/v2c/v3, ONVIF Profile S/G/T
Operating Temp. -30°C ~ +55°C (-22°F ~ +131°F)
Certifications IP66, IK10, NEMA4X
Power Supply PoE (IEEE802.3af Class 3)
Power Consumption Max. 6.5W
Dimensions / Weight 99(W) × 52(H) × 100(D) mm (3.88 × 2.08 × 3.94 in), 295g (0.65 lb)

Warranty Information

Hanwha Vision offers warranty support tailored to the Australian and New Zealand markets, with robust local servicing and technical support through authorized partners.

Brand Description

Hanwha Vision (formerly Samsung Techwin) is a global leader in advanced video surveillance solutions, blending innovative technology, AI-powered analytics, and durable hardware designed for critical environments.

SKU

HV-XNV-6012

Practical Use Scenarios

✅ Ideal for transportation infrastructure requiring wide-angle monitoring.
✅ Suitable for exterior building facades where discreet yet durable cameras are required.
✅ Perfect for areas needing robust environmental protection without sacrificing image quality.
✅ Great choice for compact installations demanding advanced analytics without IR illumination.

Datasheets & Downloadable Resources

Excellence for the Australian and New Zealand Market

Hanwha Vision ensures that the HV-XNV-6012 complies with Australian and New Zealand safety and quality standards. All products are sourced via authorized distribution channels, and warranty and technical support are handled locally for peace of mind and fast service resolution.

FAQs

Q1: What is the field of view for the Hanwha HV-XNV-6012 (SKU: HV-XNV-6012)?
A1: It offers a wide horizontal field of view of 135.4°, perfect for broad area surveillance.

Q2: Does the Hanwha HV-XNV-6012 (SKU: HV-XNV-6012) support IR night vision?
A2: No, this model does not include built-in IR LEDs but offers excellent low-light performance down to 0.004 Lux in black & white.

Q3: What analytics does the Hanwha HV-XNV-6012 (SKU: HV-XNV-6012) provide?
A3: It includes motion detection, face detection, tampering, loitering, virtual line, fog detection, and audio detection.

Q4: Can the Hanwha HV-XNV-6012 (SKU: HV-XNV-6012) record locally?
A4: Yes! It has a microSD slot supporting up to 256GB of onboard storage for edge recording.

Q5: What kind of weather protection does the Hanwha HV-XNV-6012 (SKU: HV-XNV-6012) offer?
A5: It’s IP66, IK10, and NEMA4X rated, providing excellent protection against dust, water, and impact.
