Hanwha Vision Wisenet X-Series HV-XNF-9010RVM 12MP 4K IR Vandal-Dome Fisheye Camera – 1.08mm Lens, Onboard Dewarping, Heatmap, M12 Connector, IP66, IK10, NEMA4X | SKU: HV-XNF-9010RVM x series

[Special Order Item: May take longer for product to be posted]

The Hanwha Vision HV-XNF-9010RVM Wisenet X-Series 4K IR Vandal-Dome Fisheye Camera is engineered for demanding environments where high-resolution panoramic coverage and advanced analytics are paramount. Designed with transportation and mobile applications in mind, this rugged fisheye camera delivers exceptional image quality, business intelligence insights, and robust physical protection in a compact and reliable form factor.

At its core, the HV-XNF-9010RVM integrates a 12MP CMOS sensor, offering up to 9MP effective video output for ultra-clear, immersive visuals. The 1.08mm stereographic fisheye lens captures a full 187° horizontal, vertical, and diagonal field of view, providing comprehensive situational awareness without blind spots.

Key features include:

• Multiple Viewing Modes: Supports fisheye, single panorama, double panorama, and quad views, with onboard dewarping and digital PTZ capabilities for flexible video display options.

• ExtremeWDR (120 dB) ensures superior image clarity in scenes with high contrast lighting.

• Low-Light Performance: Achieves color imaging down to 0.39 Lux and 0 Lux with IR illumination.

• WiseIR Technology offers IR visibility up to 10 meters (32.8 ft), optimizing illumination for even coverage.

Advanced AI-powered analytics transform video data into actionable intelligence, supporting features like people counting, heatmapping, queue management, motion detection, and virtual lines. This empowers users to enhance security and gain valuable operational insights.

The HV-XNF-9010RVM is built tough for mobile deployments, featuring M12 connectors for vibration resistance in vehicles and IK10, IP66, and NEMA4X ratings, safeguarding it against impact, dust, water, and harsh weather conditions. Edge storage is supported via dual microSD slots, allowing for up to 1TB of onboard recording.

For critical transportation, public space monitoring, retail analytics, or any environment demanding panoramic surveillance and rugged durability, the HV-XNF-9010RVM is a powerful and reliable choice.

What’s Included in the Box

• Hanwha Vision HV-XNF-9010RVM Wisenet X-Series 4K IR Fisheye Camera

• Installation hardware

• Quick Installation Guide

Main Features

• Ultra-High Resolution: Captures up to 3008×3008 video for clear panoramic imagery.

• 1.08mm Fisheye Lens: Full 187° coverage with enhanced peripheral resolution.

• Flexible Viewing Modes:

  • Fisheye view

  • Single panorama (4:1)

  • Double panorama (2:1)

  • Quad view

• ExtremeWDR (120 dB): Maintains clarity in scenes with extreme lighting contrast.

• Low-Light Sensitivity: Color images at 0.39 Lux, 0 Lux with IR.

• WiseIR: Intelligent infrared illumination up to 10m.

• AI-Driven Analytics:

  • Object detection

  • People counting

  • Queue management

  • Heat mapping

  • Motion detection

  • Appear/disappear events

  • Virtual lines and zones

• Onboard Dewarping & Digital PTZ: Eliminates the need for external software processing.

• Secure Connectivity: HTTPS, IP filtering, 802.1X authentication, and device certificates.

• Edge Storage: Dual microSD slots, supporting up to 1TB.

• Mobile-Ready: M12 Ethernet connection for vehicle installations.

• Environmental Durability: IP66, IK10, NEMA4X certified.

Detailed Specifications

Warranty Information

Hanwha Vision offers robust warranty support for the HV-XNF-9010RVM, ensuring reliable service and long-term peace of mind. Authorized Australian and New Zealand partners provide local warranty handling and support.

Brand Description

Hanwha Vision (formerly Samsung Techwin) is a leader in advanced video surveillance solutions, renowned for AI analytics, reliability, and cutting-edge technology across diverse industries worldwide.

SKU

HV-XNF-9010RVM

Practical Use Scenarios

✅ Ideal for public transportation systems, thanks to its M12 vibration-resistant connector.
✅ Perfect for retail spaces utilizing heatmaps and people counting for business insights.
✅ Excellent for public safety in urban environments, with panoramic views and advanced analytics.
✅ Suitable for industrial settings needing robust IP66/IK10 protection.

Datasheets & Downloadable Resources

• Hanwha Vision HV-XNF-9010RVM Datasheet (Official)

Excellence for the Australian and New Zealand Market

The Hanwha HV-XNF-9010RVM complies fully with Australian and New Zealand standards, ensuring local regulatory conformity and performance reliability. Products sourced through authorized channels come with genuine warranty support and trusted service.

 FAQs

Q1: What resolution does the Hanwha HV-XNF-9010RVM (SKU: HV-XNF-9010RVM) support?
A1: It delivers video up to 3008×3008 resolution from its 12MP sensor, offering outstanding clarity for panoramic views.

Q2: Does the Hanwha HV-XNF-9010RVM (SKU: HV-XNF-9010RVM) support onboard dewarping?
A2: Yes, it offers onboard dewarping for fisheye, single/double panorama, and quad views, reducing the need for external software.

Q3: What is the IR range of the Hanwha HV-XNF-9010RVM (SKU: HV-XNF-9010RVM)?
A3: It has a WiseIR range of up to 10 meters (32.8 ft).

Q4: Is the Hanwha HV-XNF-9010RVM (SKU: HV-XNF-9010RVM) suitable for vehicles?
A4: Absolutely. It features an M12 connector for secure vibration-resistant connections, perfect for mobile applications.

Q5: What environmental protection ratings does the Hanwha HV-XNF-9010RVM (SKU: HV-XNF-9010RVM) have?
A5: It’s certified to IP66, IK10, and NEMA4X standards, ensuring durability in harsh environments.
