Garland Figure 8 TCW14 2 x 14/0.2 Cable – 250m Roll

The Garland Figure 8 TCW14 2 x 14/0.2 Cable is a high-quality, stranded figure-8 cable designed for low-voltage applications such as electronic wiring, security systems, and speaker installations. Manufactured with precision, this cable features a durable PVC insulation in Traffic White (RAL 9016) with a white/black stripe for easy identification. Its compliance with the AS/CA S-008 standard ensures it meets Australian telecommunications safety and performance requirements.

What's Included

• 1 x 250m roll of Garland Figure 8 TCW14 2 x 14/0.2 Cable

Key Features

• Conductor: Stranded 14/0.2mm (approx. 21 AWG) Plain Annealed Copper Wire (PACW)

• Insulation: PVC (Traffic White RAL 9016) with white/black stripe

• Construction: Figure 8 configuration for easy separation and installation

• Voltage Rating: Extra Low Voltage (ELV)

• Standards Compliance: Meets AS/CA S-008 requirements

• Applications: Ideal for electronic wiring, extension speakers, and security systems

Detailed Specifications

• Conductor Size: 14 strands of 0.2mm diameter

• Conductor Area: 0.215 mm²

• Conductor Diameter: 0.6 mm

• Number of Cores: 2

• Insulation Thickness: 0.6 mm

• Nominal Outer Dimensions: 2.2 mm x 4.4 mm

• Max. Conductor DC Resistance @ 20°C: 45.2 Ω/km

• Min. Insulation Resistance @ 20°C: 50 MΩ·km

• Voltage Test: 1.5 kV AC for 1 minute

• Operating Temperature Range: -15°C to 70°C

• Max. Recommended Pulling Tension: 61 N

• Minimum Bend Radius (Installation): 22 mm

• Approximate Mass: 1.75 kg per 100 m

Warranty Information

This product is backed by the manufacturer's standard warranty. For warranty claims or support, please contact the authorized distributor or the manufacturer directly.

Brand Overview

Garland is a reputable brand known for producing high-quality cabling solutions tailored for various applications, including telecommunications, security, and audio systems. Their products are designed to meet stringent industry standards, ensuring reliability and performance.

Practical Use Scenarios

• Electronic Equipment Wiring: Suitable for connecting various electronic devices requiring low-voltage power.

• Extension Speakers: Ideal for audio installations, providing clear signal transmission.

• Security Systems: Perfect for wiring alarm systems, CCTV, and other security apparatus.

Datasheets & Resources

• Garland Figure 8 TCW14 2 x 14/0.2 Cable Datasheet (PDF)

Excellence for the Australian and New Zealand Market

• Standards Compliance: Meets AS/CA S-008 requirements, ensuring safety and performance in telecommunications applications.

• Optimized for Local Use: Designed to meet the specific needs of the Australian and New Zealand markets.

• Authorized Distribution: Sourced exclusively from authorized brand representatives, guaranteeing authenticity.

• Warranty Support: Warranty handling facilitated through direct communication with the manufacturer or authorized distributors.

 FAQs

Q1: What is the conductor size of the Garland Figure 8 TCW14 2 x 14/0.2 Cable (TCW14WH)?

A1: The conductor consists of 14 strands of 0.2mm diameter Plain Annealed Copper Wire, totaling approximately 0.215 mm².

Q2: Is the Garland Figure 8 TCW14 2 x 14/0.2 Cable (TCW14WH) suitable for outdoor installations?

A2: This cable is designed for indoor use. For outdoor applications, additional protection or a different cable type may be required.

Q3: Does the Garland Figure 8 TCW14 2 x 14/0.2 Cable (TCW14WH) comply with Australian standards?

A3: Yes, it complies with the AS/CA S-008 standard, ensuring it meets Australian telecommunications safety and performance requirements.

Q4: What is the maximum operating temperature for the Garland Figure 8 TCW14 2 x 14/0.2 Cable (TCW14WH)?

A4: The cable operates effectively within a temperature range of -15°C to 70°C.

Q5: Can the Garland Figure 8 TCW14 2 x 14/0.2 Cable (TCW14WH) be used for speaker installations?

A5: Yes, it is ideal for extension speaker wiring, providing reliable signal transmission.
