DAHUA DH-PFB302S wall mount bracket with ip66 junction box suits speed dome ptz

Name: DAHUA DH-PFB302S wall mount bracket with ip66 junction box suits speed dome ptz
Brand: CCTV Tradie
SKU: DH-PFB302S-SEC

DAHUA DH-PFB302S wall mount bracket with ip66 junction box suits speed dome ptz

$48.96 AUD

~~$60.18 AUD~~ $48.96 AUD

Sale Sold out

Duties and taxes included. Shipping calculated at checkout.

Introducing the Dahua Wall Mount Bracket with IP66 Junction Box, the ultimate solution for securely installing your surveillance cameras. Designed to accommodate a variety of camera types including dome, fisheye, mini PTZ, and speed dome PTZ models, this versatile bracket ensures compatibility with a range of Dahua products.

Delivery can take longer than usual for this product. Please enquire CCTVImporters for express shipping availabilities.

Crafted from durable white aluminum, this bracket not only offers a sleek and modern appearance but also provides robust support for your camera setup. With a maximum load capacity of 4 kg, it can easily handle the weight of your surveillance equipment, providing stability and peace of mind.

Equipped with a G3/4" thread, installation is quick and hassle-free, allowing you to effortlessly mount your cameras in the desired location. The IP66-rated junction box offers protection against dust and water ingress, ensuring reliable performance even in challenging environmental conditions.

Compact yet sturdy, this wall mount bracket measures 133.5mm in height, 134mm in width, and 187.5mm in depth, making it suitable for a variety of installation scenarios. Weighing just 0.7 kg, it adds minimal bulk while delivering maximum support.

Backed by a generous 36-month warranty, the Dahua Wall Mount Bracket with IP66 Junction Box is built to last, providing long-term security for your surveillance infrastructure. Elevate your surveillance setup with this reliable and versatile mounting solution from Dahua.

Technical Specifications	Details
Model	DH-PFB302S
General
Material	Aluminum
Dimension (W x H x D)	134.0mm x 133.5mm x 187.5mm
	(5.28” x 5.25” x 7.38”)
Pipe Thread	G3/4”
Weight	0.7kg (1.54lb)
Load Bearing	4.0kg (8.82lb)
Color	White
Protection	IP66
Operating Temperature	-40ºC to 60ºC (-40℉ to 140℉)
Humidity	0 to 90% RH
Applicable Model	Please see “Accessory Selection”
