AJAX#30622 Ajax DoorProtect Plus Jeweller Wireless Opening, Shock & Tilt Detector – White / Black | Advanced Door & Window Sensor
AJAX#30622 Ajax DoorProtect Plus Jeweller Wireless Opening, Shock & Tilt Detector – White / Black | Advanced Door & Window Sensor
Couldn't load pickup availability
The AJAX#30622 Ajax DoorProtect Plus Jeweller Wireless Opening, Shock & Tilt Detector – White / Black is an advanced multi-function security detector designed to protect doors, windows, skylights, safes, roller shutters, and other entry points against unauthorized access and tampering. Combining a precision reed switch, integrated accelerometer, and intelligent shock and tilt detection technology, the DoorProtect Plus provides comprehensive perimeter protection for residential and commercial security systems.
Using Ajax’s encrypted Jeweller wireless communication technology, the detector instantly reports opening events, impacts, vibrations, and changes in tilt angle while delivering reliable wireless performance up to 1200 metres. Featuring adjustable sensitivity levels, support for additional wired detectors, anti-sabotage protection, and up to 5 years battery life, the DoorProtect Plus Jeweller is ideal for professional smart security installations across Australia and New Zealand.
What’s Included in the Box
- Ajax DoorProtect Plus Jeweller Detector
- SmartBracket Mounting Panel
- CR123A Battery (Pre-installed)
- Large Magnet
- Small Magnet
- Terminal for Third-Party Detector Connection
- Installation Kit
- Quick Start Guide
Main Features
Multi-Function Intrusion Detection
- Opening detection using reed switch
- Shock detection using accelerometer
- Tilt angle monitoring for movable objects
Advanced Shock & Tilt Protection
- Adjustable shock sensitivity:
- 3 levels
- Tilt activation threshold:
- Adjustable from 5° to 25°
- Option to ignore single shock events
Encrypted Jeweller Wireless Communication
- Up to 1200 m wireless range
- Dynamic key encryption and anti-jamming protection
Flexible Magnet Installation
- Includes:
- Small magnet
- Large magnet
- Magnet installs to the right side of the detector
Third-Party Detector Support
- Input for wired NC detectors
- Expands system integration flexibility
Long Battery Life
- Up to 5 years operation
- Powered by pre-installed CR123A battery
Tamper & Anti-Sabotage Protection
- Alerts if the detector is removed or tampered with
- Device authentication against spoofing
Technical Specifications
| Specification | Details |
|---|---|
| Product Code | AJAX#30622 |
| Product Name | Ajax DoorProtect Plus Jeweller |
| Detection Type | Opening, Shock & Tilt Detector |
| Sensitive Elements | Reed Switch + Accelerometer |
| Shock Sensitivity | 3 adjustable levels |
| Tilt Detection Threshold | 5°–25° adjustable |
| Wireless Technology | Jeweller |
| Wireless Range | Up to 1200 m |
| Frequency Bands | 866–926 MHz (region dependent) |
| Radio Signal Modulation | GFSK |
| Additional Input | NC Wired Detector Input |
| Battery Type | 1 × CR123A |
| Battery Life | Up to 5 years |
| Operating Voltage | 3 V |
| Operating Temperature | −10°C to +40°C |
| Operating Humidity | Up to 75% |
| Protection Rating | IP50 |
| Dimensions | Ø20 × 90 mm |
| Weight | 29 g |
| Installation Type | Indoor |
| Colour Options | White / Black |
Practical Use Scenarios
Door & Window Protection
Detects opening attempts, forced impacts, and tilt changes on doors and windows.
Roller Shutter & Skylight Monitoring
Ideal for movable structures where tilt or vibration monitoring is required.
Safe & Cabinet Protection
Provides tamper and movement detection for valuables and restricted access areas.
Smart AJAX Alarm Systems
Integrates seamlessly with Ajax hubs, sirens, and automation devices.
Hybrid Security Installations
Supports additional wired NC detectors for expanded system protection.
Warranty Information
Manufacturer Warranty: 24 Months
About Ajax Systems
Ajax Systems is a globally recognized leader in smart wireless security technology, delivering professional intrusion protection systems with encrypted communication, intelligent sensors, and advanced alarm management trusted worldwide.
Excellence for the Australian and New Zealand Market
This product is supplied through authorized distribution channels to ensure compatibility with Australian and New Zealand security standards and wireless regulations.
Key advantages include:
- Genuine Ajax Systems product
- AU/NZ compatible wireless operation
- Secure encrypted communication
- Professional installer-friendly integration
- Reliable warranty support through authorized suppliers
This ensures customers receive a secure, compliant, and highly reliable perimeter protection solution suitable for residential and commercial installations across Australia and New Zealand.
Datasheets & Resources
FAQs – AJAX#30622
1. What is the AJAX#30622 DoorProtect Plus used for?
The AJAX#30622 DoorProtect Plus Jeweller is a wireless opening, shock, and tilt detector designed for advanced perimeter protection.
2. What additional features does the AJAX#30622 offer compared to standard opening detectors?
The AJAX#30622 includes built-in shock detection and tilt detection using an accelerometer.
3. Can the AJAX#30622 detect vibration or impacts?
Yes, the AJAX#30622 DoorProtect Plus can detect impacts and vibrations with adjustable sensitivity settings.
4. What is the tilt detection range of the AJAX#30622?
The AJAX#30622 supports adjustable tilt detection thresholds from 5° to 25°.
5. Can the AJAX#30622 connect to additional wired detectors?
Yes, the AJAX#30622 DoorProtect Plus supports third-party wired NC detectors.
6. Is the AJAX#30622 suitable for outdoor use?
No, the AJAX#30622 DoorProtect Plus Jeweller is designed for indoor use only.
