AJAX#134501 Ajax 8CH HDMI Network Video Recorder (NVR) Without HDD – Black / White

The AJAX#134501 Ajax 8CH HDMI Network Video Recorder (NVR) Without HDD – Black / White is a professional-grade 8-channel surveillance recorder designed to deliver reliable video management, smart analytics, and seamless integration with Ajax security systems. Supporting high-resolution IP camera recording up to 8MP, ONVIF compatibility, RTSP streaming, and advanced video analytics, this compact NVR provides efficient and scalable monitoring for residential, commercial, and industrial security applications.

Featuring HDMI output, synchronized multi-channel playback, intelligent motion detection, AI object detection, and support for Ajax camera integration, the NVR HAC (8-ch) offers professional monitoring capabilities with secure video management and privacy controls. With support for up to 16 TB SATA HDD/SSD storage (not included), H.265/H.264/JetSparrow decoding, and Ajax event-triggered camera verification, this NVR is ideal for modern smart surveillance installations across Australia and New Zealand.

What’s Included in the Box

• Ajax NVR HAC (8-ch)
• SmartBracket Mounting Panel
• Power Cable
• Ethernet Cable
• Installation Kit
• Quick Start Guide

Note: HDD/SSD storage is not included.

Main Features

8 Channel IP Camera Support

• Supports up to 8 IP camera channels

High Resolution Recording

• Recording resolutions up to:
  • 8MP
  • 6MP
  • 5MP
  • 4MP
  • 1080p and more

HDMI Video Output

• HDMI output resolutions up to Full HD
• Supports live monitoring and playback

Advanced Video Compression

• H.265
• H.264
• JetSparrow decoding support

Built-In Smart Video Analytics

• Motion detection
• AI object detection
• Smart event filtering

Ajax Security Integration

• Automatic camera pop-up during Ajax alarm events
• Visual alarm verification support

Flexible Camera Compatibility

• Supports:
  • Ajax cameras
  • ONVIF Profile S/T cameras
  • RTSP-compatible IP cameras

Expandable Storage

• 1 × SATA HDD/SSD support
• Up to 16 TB capacity
• Supports 2.5" and 3.5" drives

Professional Video Wall Interface

• Integrated video wall with multiple layouts
• Interactive playback timeline

Privacy & Access Control

• Configurable user permissions
• Secure access management for installers and monitoring operators

Technical Specifications

Practical Use Scenarios

Residential Video Surveillance
Monitor homes and apartments with high-resolution recording and Ajax alarm integration.

Commercial Security Systems
Ideal for offices, retail stores, and commercial facilities requiring multi-camera management.

Industrial & Warehouse Monitoring
Supports large-scale IP camera deployments with advanced playback and analytics.

Integrated AJAX Alarm Systems
Provides visual verification of Ajax intrusion events through synchronized camera monitoring.

Professional CCTV Installations
Flexible ONVIF and RTSP compatibility for broad IP camera support.

Warranty Information

Manufacturer Warranty: 24 Months

About Ajax Systems

Ajax Systems is a globally recognized leader in smart security and video surveillance technology, delivering intelligent intrusion protection, encrypted communication, and advanced video management solutions trusted worldwide.

Excellence for the Australian and New Zealand Market

This product is supplied through authorized distribution channels and optimized for professional surveillance installations throughout Australia and New Zealand.

Key advantages include:

• Genuine Ajax Systems product
• AU/NZ compatible operation
• Advanced video analytics and smart playback
• ONVIF and RTSP camera compatibility
• Secure privacy and user access controls
• Reliable warranty support through authorized suppliers

This ensures customers receive a secure, scalable, and professional video surveillance solution suitable for residential and commercial security installations across Australia and New Zealand.

Datasheets & Resources

• Technical Specifications

  NVR H series device user manual

  Technical Datasheet

These resources provide detailed installation guidance, camera compatibility information, recording setup instructions, and advanced configuration recommendations for professional Ajax installers and surveillance integrators.

FAQs – AJAX#134501

1. What is the AJAX#134501 NVR used for?
The AJAX#134501 NVR HAC (8-ch) is an 8-channel network video recorder designed for professional IP camera surveillance systems.

2. Does the AJAX#134501 support 8MP recording?
Yes, the AJAX#134501 supports recording resolutions up to 8MP.

3. Does the AJAX#134501 include a hard drive?
No, the AJAX#134501 NVR is supplied without HDD or SSD storage.

4. What storage capacity does the AJAX#134501 support?
The AJAX#134501 supports up to 16 TB SATA HDD or SSD storage.

5. Is the AJAX#134501 compatible with ONVIF cameras?
Yes, the AJAX#134501 NVR supports ONVIF Profile S/T and RTSP-compatible IP cameras.

6. Can the AJAX#134501 integrate with Ajax alarm systems?
Yes, the AJAX#134501 supports visual verification scenarios triggered by Ajax security system alarms.
